discontinued; see below for product recommendations
Analog I/O cards:
CIML4 (discontinued; consider the QIO Series network audio I/O expanders)
Mic/Line Analog Input Card:
Four channels of switchable microphone and/or line-level analog audio input with 48 V phantom power as well as high-quality preamplification and A/D conversion. This card provides inputs for microphones, mixers and CD/DVD players.
CIML4-HP (discontinued; consider the QIO Series network audio I/O expanders)
High Performance Mic/Line Analog Input Card:
Four channels of switchable microphone and/or line-level analog audio input with 48 V phantom power. Features broadcast quality preamplification and A/D conversion. This card provides inputs for microphones, mixers and CD/DVD players.
COL4 (discontinued; consider the QIO Series network audio I/O expanders)
Analog Line Output Card:
Four channels of balanced, line-level analog output for interfacing between Q-SYS™ and outboard equipment such as non-DataPort amplifiers, recording devices and teleconference systems.
DataPort Output Card:
Four audio output channels (2 DataPort connectors) for connection to DataPort equipped Q-SYS amplifiers. The DataPort interface allows audio, status monitoring, and control between the Q-SYS Platform and Q-SYS DataPort power amplifiers.
CTEL4 (discontinued; consider the Q-SYS Core 110f for POTS connectivity)
Analog Telephony Card (POTS):
Provides four RJ-11 interfaces to connect Q-SYS Core to analog telephony environments.
Network Bridge cards:
CDN64 (discontinued; The Software-based Dante feature license lets you add Dante network I/O to any current Q-SYS Core processor.)
Dante™ Audio Bridge Card:
Provides a link for up to 64x64 channels at 48 kHz from any Dante™ edge network, such as wireless microphones and digital mixers, directly into the Q-SYS ecosystem for advanced processing and redistribution over Q-Lan for larger LAN and WAN IT infrastructures.
The CDN64 Dante Bridge Card is ideal for use in performance venues such as theaters, auditoriums, convention centers, and houses of worship.
Digital AES cards:
AES-3 Digital Input/Output Card:
Four input and four output channels of AES-3 digital audio for interfacing between Q-SYS and digital devices such as mixing consoles and recording devices.
AES/EBU Input Card:
CIAES16 is a 16-channel AES/EBU (AES3) 24-bit digital input Q-SYS peripheral card that can be used in any Q-SYS Core or I/O Frame. Utilizes IT industry standard RJ45 connectors. It provides a simple and cost-effective way to interface Q-SYS into an existing or new installation.
