ILA Series

ILA is a line array system designed specifically for installation in a variety of venues including houses of worship, sports facilities, clubs and other entertainment venues. ILA System v2 is a complete system consisting of line array, subwoofer, processing, amplification and suspension accessories. The result is an accessible system with very high performance, moderate cost and ease of deployment.
Most line array systems currently available are designed for touring applications, which require extreme ruggedization and expensive suspension hardware. As a result, overall system cost is driven beyond the means of many facilities that could benefit from line array performance.
SELECT A MODEL
Loudspeaker
Model | WL2082i |
Speaker | Dual 8-inch + comp. driver, biamp/triamp |
Power Continuous / Program / RMS Voltage | HF 100 W / 400 W / 40 V LF, MF 200 W / 800 W / 57 V |
Impedance | HF: 16Ω LF biamp: 8Ω LF, MF triamp: 16Ω |
Peak SPL | 132 dB |
Input Connectors | 2 x NL8 |
Dimensions (HWD) inches | 11.8 x 27 x 13.4 |
Dimensions (HWD) mm | 300 x 686 x 340 |
Net Weight | 37 lb / 16.8 kg |
Details |
All specifications are subject to change without notice.
Subwoofers
Model | WL118-sw | |
Speaker | Single 18-inch | |
Power Continuous / Program / RMS Voltage | 850 W / 3400 W / 82 V | |
Impedance | 8Ω | |
Peak SPL | 134.5 dB | |
Input Connectors | 2 X NL8/ 2 X NL4 | |
Dimensions (HWD) inches | 22.1 X 27.6 X 30.3 | |
Dimensions (HWD) mm | 562 X 702 X 771 | |
Net Weight | 111 lb/ 50.4 kg | |
Details |
All specifications are subject to change without notice.
